Standard Spindle
Auto Tool Change
Horsepower – 6.0 Hp 4.5kW
RPM Range – 6,000 – 24,000
Collet – ER32

Optional Spindle
Auto Tool Change
Horsepower – 11.0 Hp 6.5kW
RPM Range – 6,000 – 24,000
Tool Holders – 9
Tool Holder Type ISO30 / ER32 Collet

Turning Workstation
Length – 36”
Swing Diameter – 15”
Bed Adjustment Angle – 0 – 3.9 Degrees
Bed Adjustment Method – CNC Control

Dimensions
Footprint – ?
Weight – ?

Electrical Requirements
(Standard Spindle)
Voltage – 220
Amperage – 50
Phase – Single

(Optional Spindle)
Voltage – 220
Amperage – 50
Phase: Three
